The 2198-C1020-ERS belongs to the Allen‑Bradley Kinetix 5300 series single-axis servo drive under Rockwell Automation. It is a 200V class servo controller that supports EtherNet/IP CIP Motion real-time motion control communication. It is designed for standard OEM automation equipment and can cooperate with Logix family controllers and matched Kinetix TLP servo motors to realize closed-loop position, speed and torque control. The ERS suffix indicates the hardwired Safe Torque Off (STO) safety function, which meets basic machine safety requirements without additional safety relay configuration in most scenariosRockwell A....

Product Parameters

1. Catalog No.: 2198-C1020-ERS

2. Series: Kinetix 5300

3. Voltage Class: 200V

4. Output Power: 3.13kW (three-phase 230V AC), 2.02kW (single-phase 230V AC), 0.97kW (single-phase 110V AC)

5. Communication Interface: Dual-port EtherNet/IP, support linear, star and DLR ring topology

6. Safety Function: Hardwired STO (Safe Torque Off)

7. Control Modes: Position control, speed control, torque control

8. Cooling Method: Convection cooling

9. Installation: Standard DIN rail mounting

10. Certifications: CE, UL, KC, RCM, TUV safety certification

11. Warranty: 12 months standard factory warranty

12. Country of Origin: Mexico

Product Advantages

1. Integrated dual Ethernet ports support DLR ring network, simplifying on-site wiring and improving network fault tolerance.

2. Built-in hardwired STO safety function, reducing peripheral safety component costs and cabinet layout space.

3. Compact body size saves cabinet installation space, suitable for standard OEM machine integration.

4. Adopt CIP Motion protocol, seamlessly matched with CompactLogix and ControlLogix controllers, unified programming in Studio 5000 software.

5. Support automatic motor tuning, shorten servo debugging cycle and reduce engineer configuration workload.

6. Wide voltage input adaptability, compatible with single-phase and three-phase 200V power supply environments.

7. Complete fault diagnosis and status indicator, convenient for daily maintenance and troubleshooting.

Notes

1. The servo drive must be installed in an IP20 control cabinet to avoid dust, conductive debris and liquid splashing.

2. It is required to match the specified Kinetix TLP servo motor; mismatched motors may cause overload, overcurrent or encoder communication failures.

3. The power cable and encoder cable need to use Rockwell specified shielded cables, and the shielding layer must be reliably grounded to suppress electromagnetic interference.

4. The STO safety circuit must follow the wiring specifications in the official manual; random short connection will lead to hidden safety hazards of the equipment.

5. Leave sufficient heat dissipation gaps between adjacent servo drives, do not stack closely, and ensure good cabinet ventilation.

6. Do not plug or unplug power terminals and encoder terminals when powered on, otherwise internal power components may be permanently damaged.

7. Confirm the input power type (single-phase or three-phase) before power-on, wrong wiring will burn the drive main circuit.

8. Keep the firmware version consistent with the AOP file version in Studio 5000 to prevent configuration download exceptions.

Product Application

The 2198-C1020-ERS servo drive is widely used in medium and small automation OEM equipment, including packaging machinery, material handling and transplanting equipment, automated assembly machines, small cutting equipment, textile machinery, printing auxiliary equipment, lithium battery front-end handling mechanism, food processing automation equipment and other occasions requiring single-axis or multi-axis synchronous positioning control. It is especially suitable for projects that require EtherNet/IP bus and basic STO safety functions.

！
