ABB GHS2701916R0001 Analog Input Module

GHS2701916R0001   ABB    Dual Channel Transmitter

Product Detailed Description

ABB PM590-ETH is a high-performance CPU processor module belonging to the ABB AC500 PLC series, order code 1SAP150000R0271. It serves as the core control unit of the AC500 programmable logic controller system, equipped with built-in Ethernet port, dual configurable RS232/RS485 serial interfaces, FBP fieldbus plug interface, SD card slot and LCD display with 8 function keys. It supports standard IEC 61131-3 programming, and can be expanded with S500 / S500-eCo digital & analog I/O modules to build centralized or distributed industrial automation control systems.

Product Parameters

1. Model: PM590-ETH

2. Order No.: 1SAP150000R0271

3. Program Memory: 2 MB

4. Power Supply: DC 20.4 ~ 28.8 V (Rated 24 VDC)

5. Execution Speed: Bit instruction 0.002 ms / 1k; Word instruction 0.006 ms / 1k; Floating-point instruction 0.006 ms / 1k

6. Communication Interfaces: 1 × Ethernet (TCP/IP, Web server, SNTP, IEC60870-5-104); 2 × RS232/RS485 configurable (Modbus RTU, CS31 master); 1 × FBP fieldbus expansion port

7. Storage: SD card slot for program backup, firmware upgrade and data logging

8. Display: LCD screen + 8 function keys for local diagnosis and status checking

9. Max Local Expansion: Up to 10 I/O modules, max 320 local I/O points

10. Protection Class: IP20

11. Operating Temperature: 0 ℃ ~ +60 ℃

12. Storage Temperature: -40 ℃ ~ +70 ℃

13. Dimension (H×W×D): 76 mm × 67.5 mm × 62 mm

14. Weight: Approx. 0.137 kg

15. Mounting: Standard DIN rail mounting

16. Compliance Certificates: CE, RoHS, REACHeero

Product Advantages

1. Rich built-in multi-communication ports, supports Ethernet and serial protocols simultaneously, no extra communication module required for most networking scenarios, reduces system cost.

2. Compatible with full AC500 series I/O modules and Automation Builder programming software, smooth upgrade path with other AC500 CPUs, good compatibility for system reconstruction and expansion.

3. Onboard LCD display and function keys support on-site local monitoring, fault diagnosis and simple operation, convenient for field maintenance.

4. SD card function supports one-click program backup and restore, fast firmware update, greatly shortens downtime during commissioning and maintenance.

5. Compact DIN rail installation design, saves cabinet space, stable operation in standard industrial cabinet environment.

6. Supports CS31 bus distributed I/O expansion, suitable for distributed automation architecture, easy to connect with sensors, servo drives, HMI and upper monitoring systems.

Notes

1. This module is IP20 protection, must be installed inside a sealed control cabinet to avoid dust, water splash and conductive debris.

2. Use regulated 24 VDC power supply; ensure stable power input to prevent voltage fluctuation causing CPU reset or program loss.

3. Wiring must be powered off; separate power cable and signal cable to reduce electromagnetic interference, shielded cable is recommended for long-distance serial / Ethernet wiring.

4. SD card should use ABB compatible specification; do not hot plug SD card during program running to avoid data corruption.

5. Match corresponding S500 / S500-eCo I/O modules during expansion; do not exceed the maximum 10 local I/O modules limit.

6. Programming follows IEC 61131-3 standard; firmware upgrade must use official matching firmware file, wrong firmware will cause module failure.

7. Storage environment must avoid high humidity, corrosive gas and strong vibration; long-term storage temperature cannot exceed the specified range.

8. If used with fieldbus expansion modules via FBP interface, confirm protocol compatibility before configuration.

Product Applications

1. Machinery manufacturing: Assembly lines, conveying equipment, special machine tools, packaging machinery control

2. Water treatment: Sewage treatment, water supply and pumping station automatic control

3. Energy industry: Solar tracking system, small wind turbine control, power monitoring

4. Food & beverage: Production line automation, batching and process control

5. Building infrastructure: HVAC, pumping system, building auxiliary equipment control

6. Logistics automation: Sorting equipment, automated warehouse peripheral control

7. General factory distributed automation and small & medium process control projects
