PX1-6704 NI

PX1-6704    NI     Sinking digital input module

The Allen-Bradley 22B-D6P0N104 is a model within the PowerFlex 40 series of AC drives, manufactured by Rockwell Automation. It is designed for various industrial applications requiring efficient motor speed control.

Product Details:

• Series: PowerFlex 40

• Manufacturer: Allen-Bradley (Rockwell Automation)

• Type: AC Drive (Variable Frequency Drive - VFD)

• Frame Size: B

• Enclosure: IP20 (Open Type), suitable for panel mounting. NEMA/UL Type Open.

• User Interface: Integral Keypad with LED Display, providing basic control and monitoring.

• Communication: Equipped with an RS485 communication port for integration into control systems.

• Brake IGBT: Includes a Brake IGBT (Insulated Gate Bipolar Transistor), which is a key component for dynamic braking applications, allowing for faster deceleration of the motor.

Product Parameters:

• Input Voltage: 380-480V AC, 3 Phase

• Input Frequency: 50-60 Hz

• Output Power: 2.2 kW (Kilowatts) / 3 HP (Horsepower)

• Output Current: 6 Amps

• Power Factor: 0.98

• Control Modes: Supports V/Hz (Volts per Hertz) control and Sensorless Vector Control, and often includes process PID (Proportional-Integral-Derivative) capabilities for closed-loop process control.

• Dimensions: Approximately 7.25 x 5.25 x 4 inches (Product dimensions may vary slightly depending on the source).

• Weight: Approximately 6.65 pounds.

Product Advantages:

The Allen-Bradley PowerFlex 40 series, including the 22B-D6P0N104, offers several advantages for industrial applications:

• Cost-Effective Solution: Provides a balanced set of features at an economical price point, making it suitable for a wide range of general-purpose applications.

• Compact Design: Its compact size allows for efficient panel space utilization.

• Ease of Use: The integral keypad and LED display simplify configuration, operation, and troubleshooting.

• Versatile Control: Supports both V/Hz and sensorless vector control, offering flexibility for different motor types and application requirements.

• Integrated Features: Includes an integral Brake IGBT for dynamic braking and an RS485 communication port for straightforward integration into control networks.

• Process Control Capabilities: Built-in PID functionality enables the drive to directly manage process variables, reducing the need for external controllers in some applications.

• Reliability: As an Allen-Bradley product, it benefits from Rockwell Automation's reputation for robust and reliable industrial control equipment.

Static Sequence Control Board & General Drive Controller Module Applications:

While the 22B-D6P0N104 itself is an AC drive, it functions as a general drive controller module within a broader automation system. It does not typically house a "static sequence control board" as a standalone, dedicated component. Instead, sequential control is often managed by a Programmable Logic Controller (PLC) or Programmable Automation Controller (PAC) that
